FTL50H-ATC2AC4E6B Level Switch

The Endress+Hauser tuning fork limit detection FTL50H-ATC2AC4E6B is an integrated tuning fork limit switch, suitable for liquid medium measurement, especially in the fields of food and life sciences

Application field

· The Liquiphant FTL50H tuning fork limit switch can be used in hazardous areas. It has passed multiple international certifications and obtained hygiene certifications such as 3-A, EHEDG, and ASME BPE. It is particularly suitable for the fields of food and life sciences. The functional safety level of FTL50H reaches SIL2/SIL3, with stable measurement values that are not affected by medium flow, disturbance, bubbles, foam, vibration, solid content or adhesion.

· The limit switch with a fully welded housing design is suitable for liquid measurement

· Process connection: Threaded, flange and sanitary connection (clamp, milk joint, aseptic type, DRD, SMS, Varivent)

· Temperature: -50... +150°C (-58 ...  +302°F)

· Pressure: -1... +64bar (-14.5...) +928psi)

· Sensor material: 316L

· International explosion-proof certification, WHG overflow protection, SIL, sanitary certification, ship class certification

Advantage

· It can be used in safety systems with functional safety level requirements of SIL2/SIL3 and complies with the IEC 61508/IEC 61511-1 standard

· Multiple process connections are available for selection

· Equipped with a variety of electronic plug-in types, such as NAMUR, relays, semiconductor thyristors, and PFM signal outputs, it enables connection with various process control systems

· The PROFIBUS PA communication protocol can also be selected

· No calibration required: Quick and economical device startup mode

· There are no mechanical moving parts, no maintenance required, no wear and tear, and a long service life. It can monitor the damage of the fork body to ensure normal function

· Fda-certified Materials (PFA Edlon)

· Liquid limit detection
